GODO CE certified Inherent self priming design OEM electric diaphragm pump
GODO CE certified Inherent self priming design OEM electric diaphragm pump
GODO CE certified Inherent self priming design OEM electric diaphragm pump
GODO CE certified Inherent self priming design OEM electric diaphragm pump
GODO CE certified Inherent self priming design OEM electric diaphragm pump

GODO CE certified Inherent self priming design OEM electric diaphragm pump

Model NO.
A25PP-P99-C
Price:
USD 1.00-400.00 / piece
Minimum order quantity:
1 piece
Supply Ability:
2000 piece / Month
Country of Origin:
Guangzhou
Quantity:
  • Place of Origin:CN;GUA
  • Structure:Diaphragm Pump
  • Power:Pneumatic
  • Brand Name:BSK
  • Usage:Air Pump
  • Standard or Nonstandard:Standard
  • Model Number:A25PP-P99-C
  • Pressure:8.3 Bar
  • Fuel:Air
  • Application:Liquid pumping
  • Theory:Air operated diaphragm pump
  • Air Inlet:1/4-18NPTF-1
  • Liquid Outlet:1-11-1/2NPTF-1,Rp1-11BSP
  • Liquid Inlet:1-11-1/2NPTF-1,Rp1-11BSP
  • Max Flow:135L/Min
  • Max Head:70M/Water
  • Max Self-Priming Lift(Dry):4M
  • Max Air Pressure:8.3Bar
  • Max Particle Diameter:3mm
  • Max Installation Dimension:244*360.5*245
  • Weight:14.5KG







Model No.Pipe SizeAir side/
Fluid side Material
Seat MaterialDiaphragm/Ball
Material
A25PP-P99-C1’inchPolypropylene
(PP)
Polypropylene
(PP)
Santonprene
Product Description

Pneumatic diaphragm pump is a new transport machinery , is currently one of the most

 innovative pump . Using compressed gas as a power source for a variety of corrosive

liquid , with particles of liquid , high viscosity , volatile, flammable, poisonous liquid

can be pumped optical exhaustion . There are four pneumatic diaphragm material: plastic

 , aluminum, cast iron , stainless steel. Pneumatic diaphragm pumps were used nitrile
rubber,neoprene , Viton , Teflon , depending on the liquid medium , poly ethylene

fortysix . To meet the needs of different users . Placed in a variety of special occasions,

 for pumping a variety of conventional pumps can not pump the media , have achieved

satisfactory results.

Product Application
*PCB Shopspumping sewage/etching liquid for circuit board
