Good quality solid waste water sewage pump with lowest price
Good quality solid waste water sewage pump with lowest price

Good quality solid waste water sewage pump with lowest price

Model NO.
BA25AL-PTT3-A
Price:
USD 1.00-300.00 / piece
Minimum order quantity:
1 piece
Supply Ability:
2000 piece / Month
Country of Origin:
Guangzhou
Quantity:
  • Place of Origin:CN;GUA
  • Structure:Diaphragm Pump
  • Power:Pneumatic
  • Brand Name:BSK
  • Usage:Air Pump
  • Standard or Nonstandard:Standard
  • Model Number:BA25AL-PTT3-A
  • Pressure:8.3 Bar
  • Fuel:Air
  • Application:Liquid pumping
  • Theory:Air operated diaphragm pump
  • Air Inlet:1/4-18NPTF-1
  • Liquid Outlet:1-11-1/2NPTF-1,Rp1-11BSP
  • Liquid Inlet:1-11-1/2NPTF-1,Rp1-11BSP
  • Max Flow:135L/Min
  • Max Head:70M/Water
  • Max Self-Priming Lift(Dry):4M
  • Max Air Pressure:8Bar
  • Max Particle Diameter:3mm
  • Max Installation Dimension:249.5*360.5*245
  • Weight:9.5KG



Model No.Pipe SizeAir side/
Fluid side Material
Seat MaterialDiaphragm/Ball
Material
BA25AL-PTT3-A1’inchAluminium Alloy
(AL)
Polypropylene
(PP)
PTFE
Product Description

Pneumatic diaphragm pump is a new transport machinery , is currently one of the most

 innovative pump . Using compressed gas as a power source for a variety of corrosive liquid ,

with particles of liquid , high viscosity , volatile, flammable, poisonous liquid can be pumped

optical exhaustion . There are four pneumatic diaphragm material: plastic , aluminum, cast

iron , stainless steel. Pneumatic diaphragm pumps were used nitrilerubber,neoprene , Viton ,

 Teflon , depending on the liquid medium , poly ethylene forty-six . To meet the needs of different

 users . Placed in a variety of special occasions , for pumping a variety of conventional pumps can

not pump the media ,have achieved satisfactory results.

Product Application
*Sandering
machinery

Grinding varnish.There have lots of bead mills in varnish and

chemical factories.Need pumps can start up with low pressure and

endure 85 Celsius.

*

Moving baggy

 filter

Industrial wastewater filtration or chemical material

separation

*Material MixerChemical machinery or chemical plant use
*Ink/printing
 machinery

Mainly transfer ink. ep: printing machinery of

newspaper/magazine's .

*Pressure filter

Plate-and-frame type filter press, for filter polluted

water and separate
moisture material.

*Packaging
 Machinery
Pumping adhesives or glass glue etc.
*Chemical Factory

Material handling or removable barrels material

 ( instead of drum pumps )

*

Paint Filling

Machine

pumping varnish for filling and packaging
*

Ceramic glaze

 toner

For fully automatic tinting system and production

 equipments of painting, used in coatings, paints,

inks, wallpaper , wallpaper , wood, paper , flexible

packaging , ceramics, printing and dyeing , leather,

 chemicals and other toner printing and dyeing

industry.

*

Automatic ink

tinting system

*

Automatic feeding

 of chemical raw

materials distributor

*

Painting automatic

 tinting system

*

Automated Liquid

Filling tinting system

*Ball crusherInternal agitation energy ball mill can be used for wet grinding production
*TanneriesPumping dye and sewage treatment
*Battery MachinePumping the material into the mixing bucket
*Gravure pressFinish the upgrading and cycling of the ink and glue.
*Spreader
*Dyeing printing
presses
*Dry laminating
machine
*Stencil CleanerEmerging industries ( steel washing machines or stencil cleaning machines)
